Description
Features
Binary Inputs:
Clock In
Reset In
Loop Gate In
Binary Outputs:
Gate/Trigger Outputs 1-8
CV Inputs:
Probability, channel 1
Probability, channel 8
Loop Length
CV Output:
CV Out jack sends stairstep-type random looping CV sequences, based on the states of the 8 Gate Outputs
Trig/Gate switch sets outputs to send either gates or triggers – trigger and gate lengths can be set using the System Mode
Div Switch engages Divider mode
Reset pushbutton resets Loop and/or Divider count
Loop illuminated pushbutton engages looping and displays loop status
Specifications
16HP
Current draw: +12V: 25mA, -12V: 1mA (using 5V power, 5V: 25mA, -12V: 1mA)
Depth: 21mm
Metal shaft potentiometers, 100,000 cycle life, bolted to panel
Jumper selection for internal/external 5v power
Reverse polarity power protection, full over/under voltage protection on all CV/gate inputs
Header for the 8 outputs allows for future expander connection or your own DIY expanders
Binary inputs trigger at a threshold level of ~1.5V and are conditioned to trigger reliably even from non-pulse waveforms
Binary outputs are 0V when low and 5V when high
CV inputs are natively 0V to 5V; built-in attenuators and offsets allow any normal modulation signal to be accepted
CV output is in the range 0V-5V
Clock input accepts clocks up to 1kHz, or 1000 cycles per second for audio rate pitched noise and random wavetable oscillator purposes
Includes 16-page printed manual, four M3x6 mounting screws, 16-to-16-pin power cable
